Two Groups Low Temperature Bending Test Machine for Cable and Wires

Ask Lasest Price
Brand Name :	AI
Model Number :	AIC-6034A
Certification :	ISO
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union
Delivery Time :	20 days
Supply Ability :	100 Sets per Month

Add to Cart

Product Details
Company Profile

Two Groups Low Temperature Bending Test Machine for Cable and Wires

Low Temperature Bending Test Machine

Introduction

It is suitable to examine and test the performance under low temperature for circular insulating core wire under Φ12.5m and Sector Insulated Wire Core which can not make Dumbbell test specimen(Shorter axis of sheath≦20mm flat cable).

Reference standards

● GB2951.14-2008, Sect 8.1&8.2 Common test methods for insulating and sheathing materials of electric and optical cables - Part 14: Methods for general application - Test at low temperature

● IEC60811-1-4:2001 INSULATING AND SHEATHING MATERIALS OF ELECTRIC CABLES - COMMON TEST METHODS - PART 1-4: GENERAL APPLICATION - TESTS AT LOW TEMPERATURE

● JB/T4278.11-2011 Verification procedure for test equipment of rubber plastic wire and cable.

Technical specifications

1	Test groups	two groups
2	Dimension	420L400W300H(mm)
3	Diameter of specimen	Φ2.5~Φ12.5mm
4	Outlet diameter of guiding tube(mm)	Φ1.2,Φ2.4,Φ3.0,Φ3.8,Φ4.7,Φ5.9,Φ7.4,Φ9.2,Φ11.5,Φ14.5,totally 10 groups confirms to JB/T4278.11-2011
5	Diameter of winding rod	Φ4,Φ5,Φ6,Φ7,Φ8,Φ10,Φ12,Φ14,Φ16,Φ18,Φ20,Φ24,Φ28,Φ32,Φ36,Φ40,Φ45,Φ50mm,totally 18 pieces conforms to JB/T4278.11-2011(it can also be customized)
6	Winding mode	adjust speed manually
7	Material	SUS304
