    Contact Resistance Electrical Test Instrument For Circuit Breaker Routine Test

    Ask Lasest Price
    Brand Name : AI
    Model Number : CRT-4
    Certification : ISO
    Price : Negotiable
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 100000 sets per month
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    Contact Resistance Electrical Test Instrument For Circuit Breaker Routine Test

    400A Contact Resistance Testing Equipment


    Introduction:

    • This Contact resistance testing equipment is used to test the contact resistance of circuit breaker or high current cable contacts.

    • This instrument is designed according to IEC62271.

    • The main application of this contact resistance test instrument is measurement of circuit breaker contact resistance.

    • All the test results of contact resistance testing equipment setcould be print by the micro-printer which is integrated in the tester.

    • Also all the test results saved in the contact resistance testing equipment could be uploaded to PC computer and then convert to MS WORD document.


    Features:

    • Rapid test;

    • Result print;

    • Upload data to PC;


    Specifications:

    1Measuring range0-1999.9 μΩ Resolution:0.1 μΩ
    2Measuring currentDC 100A/200A/400A for different selection
    3Measuring precision0.5 %RGD+0.05%FS
    4Display modeLCD
    5Data storageSave no more than 100 groups of data
    6Data connectionRS232 computer interface
    7Rated power supplyAC220V
    8Size340mm× 280mm × 210mm
    9Environment temperature-10 ℃~+40 ℃
    10Relative humidity<80%

    Package List

    Main Unit1unitDisk1unit
    9m test cable1setInstruction manual1unit
    Power supply cable1unitInspection report1unit
